46.5.2 SHA Mode Register
Name: SHA_MR
Address: 0xF0014004
Access: Read-write
SMOD: Start Mode
Values which are not listed in table must be considered as “reserved”.
If a DMA transfer is used, either 0x1 or 0x2 must be configured. Refer to “DMA Mode” on page 1024 for more details.
PROCDLY: Processing Delay
When SHA1 algorithm is processed, runtime period is either 85 or 209 clock cycles.
When SHA256 or SHA224 algorithm is processed, runtime period is either 72 or 194 clock cycles.
ALGO: SHA Algorithm.
Values which are not listed in table must be considered as “reserved”.
DUALBUFF: Dual Input BUFFer
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
–––––––DUALBUFF
15 14 13 12 11 10 9 8
––ALGO
76543210
PROCDLY SMOD
Value Name Description
0x0 MANUAL_START Manual Mode
0x1 AUTO_START Auto Mode
0x2 IDATAR0_START SHA_IDATAR0 access only Auto Mode
Value Name Description
0x0 SHORTEST SHA processing runtime is the shortest one
0x1 LONGEST SHA processing runtime is the longest one
Value Name Description
0x0 SHA1 SHA1 algorithm processed
0x1 SHA256 SHA256 algorithm processed
0x4 SHA224 SHA224 algorithm processed
Value Name Description
0x0 INACTIVE SHA_IDATARx and SHA_IODATARx cannot be written during processing of previous block.
0x1 ACTIVE
SHA_IDATARx and SHA_IODATARx can be written during processing of previous block
when SMOD=0x2. It speeds up the overall runtime of large files.
