45.6 Advanced Encryption Standard (AES) User Interface
Table 45-5. Register Mapping
Offset Register Name Access Reset
0x00 Control Register AES_CR Write-only
–
0x04 Mode Register AES_MR Read-write 0x0
0x08–0x0C Reserved
–––
0x10 Interrupt Enable Register AES_IER Write-only
–
0x14 Interrupt Disable Register AES_IDR Write-only
–
0x18 Interrupt Mask Register AES_IMR Read-only 0x0
0x1C Interrupt Status Register AES_ISR Read-only 0x0
0x20 Key Word Register 0 AES_KEYWR0 Write-only
–
0x24 Key Word Register 1 AES_KEYWR1 Write-only
–
0x28 Key Word Register 2 AES_KEYWR2 Write-only
–
0x2C Key Word Register 3 AES_KEYWR3 Write-only
–
0x30 Key Word Register 4 AES_KEYWR4 Write-only
–
0x34 Key Word Register 5 AES_KEYWR5 Write-only
–
0x38 Key Word Register 6 AES_KEYWR6 Write-only
–
0x3C Key Word Register 7 AES_KEYWR7 Write-only
–
0x40 Input Data Register 0 AES_IDATAR0 Write-only
–
0x44 Input Data Register 1 AES_IDATAR1 Write-only
–
0x48 Input Data Register 2 AES_IDATAR2 Write-only
–
0x4C Input Data Register 3 AES_IDATAR3 Write-only
–
0x50 Output Data Register 0 AES_ODATAR0 Read-only 0x0
0x54 Output Data Register 1 AES_ODATAR1 Read-only 0x0
0x58 Output Data Register 2 AES_ODATAR2 Read-only 0x0
0x5C Output Data Register 3 AES_ODATAR3 Read-only 0x0
0x60 Initialization Vector Register 0 AES_IVR0 Write-only
–
0x64 Initialization Vector Register 1 AES_IVR1 Write-only
–
0x68 Initialization Vector Register 2 AES_IVR2 Write-only
–
0x6C Initialization Vector Register 3 AES_IVR3 Write-only
–
0x70–0xFC Reserved
–––
