AT91SAM9260-EK Evaluation Board User Guide 3-1
6234C–ATARM–22-Mar-07
Section 3
Board Description
3.1 AT91SAM9260
Microcontroller
• Incorporates the ARM926EJ-S™ ARM
®
Thumb
®
Processor
– DSP Instruction Extensions, ARM Jazelle
®
Technology fo r Java
®
Acceleration
– 8-KByte Data Cache, 8-KByte Instruction Cache, Write Buffer
– 200 MIPS at 180 MHz
– Memory Management Unit
– EmbeddedICE
™
, Debug Communication Channel Support
• Additional Embedded Memories
– One 32-KByte Internal ROM, Single-cycle Access At Maximum Matrix Speed
– Two 4-KByte Internal SRAM, Single-cycle Access At Maximum Matrix Speed
• External Bus Interface (EBI)
– Supports SDRAM, Static Memory, ECC-enabled NANDFlash and CompactFlash
®
• USB 2.0 Full Speed (12 Mbits per second) Device Port
– On-chip Transceiver, 2,432-byte Configurable Integrated DPRAM
• USB 2.0 Full Speed (12 Mbits per second) Host Single Port in the 208-lead PQFP
Package and Double Port in 217-ball LFBGA Package
– Single or Dual On-chip Transceivers
– Integrated FIFOs and Dedicated DMA Channels
• Ethernet MAC 10/100 Base T
– Media Independant Interface or Reduced Media Independant Interface
– 28-byte FIFOs and Dedicated DMA Channels for Receive and Transmit
• Image Sensor Interface
– ITU-R BT. 601/656 External Interface, Programmable Frame Capture Rate
– 12-bit Data Interface for Support of High Sensibility Sensors
– SAV and EAV Synchronization, Preview Path with Scaler, YCbCr Format
• Bus Matrix
– Six 32-bit-layer Matrix
– Boot Mode Select Option, Remap Command
• Fully-featured System Controller, including
– Reset Controller, Shutdown Controller
– Four 32-bit Battery Backup Registers for a Total of 16 Bytes
– Clock Generator and Power Management Controller
– Advanced Interrupt Controller and Debug Unit
– Periodic Interval Timer, Watchdog Timer and Real-time Timer
• Reset Controller (RSTC)
– Based on a Power-on Reset Cell, Reset Source Identification and Reset Output
