25.9.9 PMC Clock Generator PLL Register
Register Name: CKGR_PLLR
Access Type: Read-write
Possible limitations on PLL input frequencies and multiplier factors should be checked before using the PMC.
•DIV: Divider
• PLLCOUNT: PLL Counter
Specifies the number of slow clock cycles before the LOCK bit is set in PMC_SR after CKGR_PLLR is written.
• OUT: PLL Clock Frequency Range
To optimize clock performance, this field must be programmed as specified in “PLL Characteristics” in the Electrical Char-
acteristics section of the product datasheet.
• MUL: PLL Multiplier
0 = The PLL is deactivated.
1 up to 2047 = The PLL Clock frequency is the PLL input frequency multiplied by MUL+ 1.
• USBDIV: Divider for USB Clock (Does not Pertain to SAM73S2/16
31 30 29 28 27 26 25 24
– – USBDIV – MUL
23 22 21 20 19 18 17 16
MUL
15 14 13 12 11 10 9 8
OUT PLLCOUNT
76543210
DIV
DIV Divider Selected
0 Divider output is 0
1 Divider is bypassed
2 - 255 Divider output is the selected clock divided by DIV.
USBDIV Divider for USB Clock(s)
0 0 Divider output is PLL clock output.
0 1 Divider output is PLL clock output divided by 2.
1 0 Divider output is PLL clock output divided by 4.
1 1 Reserved.
