AT89C51ID2

4289C–8051–11/05

Interrupt Sources and

Vector Addresses

Table 56. Interrupt Sources and Vector Addresses

Number Polling Priority Interrupt Source

Interrupt

Request

Vector

Address

0 0 Reset 0000h

1 1 INT0 IE0 0003h

2 2 Timer 0 TF0 000Bh

3 3 INT1 IE1 0013h

4 4 Timer 1 IF1 001Bh

5 6 UART RI+TI 0023h

6 7 Timer 2 TF2+EXF2 002Bh

7 5 PCA CF + CCFn (n = 0-4) 0033h

8 8 Keyboard KBDIT 003Bh

9 9 TWI TWIIT 0043h

9 9 SPI SPIIT 004Bh
