Table 55. IPH1 Register
IPH1 - Interrupt Priority High Register (B3h)
Reset Value = XXXX X000b
Not bit addressable
76543210
- - - - - SPIH TWIH KBDH
Bit
Number
Bit
Mnemonic Description
7-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
6-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
5-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
4-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
3-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
2 SPIH
SPI interrupt Priority High bit
SPIH SPILPriority Level
0 0 Lowest
0 1
1 0
1 1 Highest
1TWIH
TWI interrupt Priority High bit
TWIH
TWILPriority Level
0 0 Lowest
0 1
1 0
1 1 Highest
0 KBDH
Keyboard interrupt Priority High bit
KB DH KBDLPriority Level
00 Lowest
0 1
10
1 1 Highest
