AT89C51ID2
4289C–8051–11/05
Table 52. IEN1 Register
IEN1 - Interrupt Enable Register (B1h)
Reset Value = XXXX X000b
Bit addressable
76543210
- - - - - ESPI ETWI EKBD
Bit
Number
Bit
Mnemonic Description
7-Reserved
6-Reserved
5-Reserved
4-Reserved
3-Reserved
2 ESPI
SPI interrupt Enable bit
Cleared to disable SPI interrupt.
Set to enable SPI interrupt.
1ETWI
TWI interrupt Enable bit
Cleared to disable TWI interrupt.
Set to enable TWI interrupt.
0 EKBD
Keyboard interrupt Enable bit
Cleared to disable keyboard interrupt.
Set to enable keyboard interrupt.
