AT89C51ID2
4289C–8051–11/05
Table 51. IPH0 Register
IPH0 - Interrupt Priority High Register (B7h)
Reset Value = X000 0000b
Not bit addressable
76543210
- PPCH PT2H PSH PT1H PX1H PT0H PX0H
Bit
Number
Bit
Mnemonic Description
7-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
6 PPCH
PCA interrupt Priority high bit.
PPCHPPCLPriority Level
0 0Lowest
01
10
1 1Highest
5PT2H
Timer 2 overflow interrupt Priority High bit
PT2HPT2LPriority Level
0 0Lowest
01
10
1 1Highest
4 PSH
Serial port Priority High bit
PSH PSLPriority Level
0 0Lowest
0 1
1 0
1 1Highest
3PT1H
Timer 1 overflow interrupt Priority High bit
PT1HPT1L Priority Level
00 Lowest
01
10
11 Highest
2 PX1H
External interrupt 1 Priority High bit
PX1HPX1LPriority Level
0 0Lowest
01
10
1 1Highest
1PT0H
Timer 0 overflow interrupt Priority High bit
PT0HPT0LPriority Level
0 0Lowest
0 1
10
1 1Highest
0 PX0H
External interrupt 0 Priority High bit
PX0H PX0LPriority Level
0 0Lowest
01
10
1 1Highest
