AT89C51ID2

4289C–8051–11/05

Ordering Information

Table 107. Possible Order Entries

Change Log for 4289A -

09/03 to 4289B - 12/03

1. Improvement of explanations throughout the document.

4289B - 12/03 to 4289C -

11/05

1. Added ‘Industrial & Green” product versions.

Part Number

Supply

Voltage

Temperature

Range Package Packing Product Marking

AT89C51ID2-SLSIM

2.7V-5.5V

Industrial

PLCC44 Stick AT89C51ID2-IM

AT89C51ID2-RLTIM VQFP44 Tray AT89C51ID2-IM

AT89C51ID2-SLSUM

Industrial &

Green

PLCC44 Stick AT89C51ID2-UM

AT89C51ID2-RLTUM VQFP44 Tray AT89C51ID2-UM
