15
AT89C51ID2
4289C–8051–11/05
Table 17. OSCCON Register (for AT8xC51Ix2 only)
OSCCON- Oscillator Control Register (86h)
Reset Value = XXXX X0’HSB.OSC
’’HSB.OSC’b (see Hardware Security Byte (HSB))
Not bit addressable
Table 18. CKRL Register
CKRL - Clock Reload Register
Reset Value = 1111 1111b
Not bit addressable
76543210
- - - - - SCLKT0 OscBEn OscAEn
Bit
Number
Bit
Mnemonic Description
7-Reserved
6-Reserved
5-Reserved
4-Reserved
3-Reserved
2SCLKT0
Sub Clock Timer0
Cleared by software to select T0 pin
Set by software to select T0 Sub Clock
Cleared by hardware after a Power Up
1 OscBEn
OscB enable bit
Set by software to run OscB
Cleared by software to stop OscB
Programmed by hardware after a Power-up regarding HSB.OSC (Default
cleared, OSCB stopped)
0 OscAEn
OscA enable bit
Set by software to run OscA
Cleared by software to stop OscA
Programmed by hardware after a Power-up regarding HSB.OSC(Default Set,
OSCA runs)
76543210
--------
Bit
Number Mnemonic Description
7:0 CKRL
Clock Reload Register:
Prescaler value
