AT89C51ID2
4289C–8051–11/05
Registers Table 86. EECON Register
EECON (0D2h)
EEPROM Control Register
Reset Value = XXXX XX00b
Not bit addressable
76543210
------EEEEEBUSY
Bit Number
Bit
Mnemonic Description
7 - 2 -
Reserved
The value read from this bit is indeterminate. Do not set this bit.
1 EEE
Enable EEPROM Space bit
Set to map the EEPROM space during MOVX instructions (Write or Read to
the EEPROM .
Clear to map the XRAM space during MOVX.
0 EEBUSY
Programming Busy flag
Set by hardware when programming is in progress.
Cleared by hardware when programming is done.
Can not be set or cleared by software.
