Specifications

COPYWRITER PRO SERIES DUPLICATOR MICROBOARDS TECHNOLOGY, LLC
24
Specifications:
CD Recorder Drive: 52x CD-RW speed selectable drive
Power Source: 115V/230V 50-60Hz switchable power supply
Weight: 48 pounds
Dimensions: 7.48” (W) x 17.91” (D) x 17.13” (H)
Power supply: 300W
Environment: Temperature: 40°C (104°F) / 5°C (41°F)
Humidity: 20% - 80%
Supported Formats:
CD-DA, Mixed Mode, ISO9660, Hybrid, CD-ROM Mode1/Mode2, CD-I, CD-ROM XA
Form1/form2, HFS, UFS, CD-EXTRA (CD-PLUS), CD+G (Karaoke)
Firmware Updates
Occasionally it may be necessary to load updated firmware on to the CopyWriter Pro
duplicator. You will be sent a disc containing the firmware program. Please follow these
steps to load the disc.
• Hold down the YES button and turn on power to the tower.
• The display will read “Please Wait” and the system will beep once.
• Release the YES button.
• The Reader drive will eject and the display will read “Insert Program Disc”.
• Place the firmware disc into the Reader drive and close the tray.
• The display will read “Updating” as the new firmware is being loaded.
• Once the firmware is loaded, the Reader drive will eject the disc.
• Remove the firmware disc from the Reader and close the tray.
• The CopyWriter Pro tower will now reboot and be ready for use with the new
firmware program running.
Contact Information
For technical questions or support issues, please contact Microboards Technology
technical support at PH: 952-556-1639, FAX: [phone], by email at
[e-mail]
or on the web at http://www.microboards.com.
