Specifications

4
Specifi cations:
Input Voltage:
120 Volt
Cabinet Dimensions:
RP6-2 151” H x 84” W x 56” D
RP6-3 151” H x 126” W x 56” D
RP8-2 173” H x 84” W x 56” D
RP8-3 173” H x 126” W x 56” D
Weight:
RP6-2 2318 lb.
RP6-3 3477 lb.
RP8-2 3098 lb.
RP8-3 4647 lb.
Filter Area:
RP6-2 3492 square feet
RP6-3 5238 square feet
RP8-2 4656 square feet
RP8-3 6984 square feet
Air Recuirements:
1.1 SCFM at 80 psi per second of cleaning
pulse: 5.4 scfm total.
Minimum air line 3/4 inch at 80 psi maximum.
3/4” NPT Female fi tting is standard for shop air
attachment.
Clean, dry, compressed air at the correct
pressure is required for the cleaning system
to operate correctly. It is recommended that
a pressure regulator and coalescing fi lter be
installed between the copressed air source and
the inlet to the dust collector.
Installation:
Inspection:
The Micro-Air Dust Collector is shipped on two
skids. Both skids should be inspected for any
visible damage that may have occurred during
shipment. One skid is the blower motor and
collector cabinet. The other skid will have the
following:
•
•
•
•
RP6-2 & RP8-2:
2 ea. Cust Collection Tray/Hopper
6 ea. Mounting Legs
RP6-3 & RP8-3:
3 ea. Cust Collection Tray/Hopper
8 ea. Mounting Legs
Additional equipment that may be shipper seperaly
includes:
55 Gallon Barrel Lid Kit & Explosion Kit.
RP6-2 & RP8-2
10 ea. Cross Leg Braces
2 ea. Mounting Hardware Packages Containing:
12 ea. 5/16 Hex Bolts
12 ea. 5/16 Flat Washers
12 ea. 5/16 Lock Washers
20 ea. Self-Tapping Screws
11 ft. Self Adhesive Foam
RP6-3 & RP8-3
14 ea. Cross Leg Braces
3 ea. Mounting Hardware Packages Containing:
12 ea. 5/16 Hex Bolts
12 ea. 5/16 Flat Washers
12 ea. 5/16 Lock Washers
20 ea. Self-Tapping Screws
11 ft. Self Adhesive Foam
Equipment/Tools Required:
Equipment and tools needed for proper installation
will include the following:
Crane or Lift Truck
Lift Straps or Chain
1/2” Scocket Wrench
Pipe Wrench
