PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
Tennant 5400 (12--06)
131
CYLINDRICAL BRUSH SCRUB HEAD GROUP, 610 mm (24 in) /
GRUPO DEL CABEZAL DE FREGADO CON CEPILLO CILÍNDRICO, 610 mm (24 pulg) /
GROUPE TETE DE BROSSAGE CYLINDRIQUE, 610 mm (24 in)
REF PART # DESCRIPTION QTY.
∇Y2 606760 KIT, SCRUBHEAD, CYLINDRICAL
FIELD INSTALLED
1
Y 1 604980 DMOTOR, 24V, 1500RPM, 23AMP 2
190152AM DCARBON BRUSH (PKG OF 4) 2
605305 DSPRING NEGATOR 8
Y 2 608473 DSKIRT, SIDE CYL. SCRUBHEAD 2
Y 3 223563 SHIELD, BELT 2
Y 4 222202 DSPROCKET, DRIVE 2
Y 5 222818 DSCREW, SET 8--32 X .25 NYLON 4
Y 6 397688 DBELT, SYNCHRONOUS 2
Y 7 223560 GUARD, BELT RH 1
Y 8 223561 GUARD, BELT LH 1
Y 9 15678 SCREW, M6X1X16 HEX 4
Y 10 200662017 WASHER, LOCK 6.4ID 4
Y 11 140000 WASHER, 1/4 FLAT 4
Y 12 08709 NUT, M8 HXLCK 4
Y 13 200370019 WASHER, M8.4 LOCK 4
Y 14 222209 SPRING, DOOR 2
Y 15 16931 SCREW, HEX M8 X 1.25 X 20 4
Y 16 606533 BRACKET, MOUNTING, MOTOR 2
Y 17 16931 SCREW, HEX M8 X 1.25 X 20 4
Y 18 130773 WIRE TIE 4
Y 19 606795 DHARNESS, MOTOR 2
Y 20 607805 BRACKET, CYL--HEAD, LH 1
Y 21 607804 BRACKET, CYL--HEAD, RH 1
Y 22 16931 SCREW, HEX M8 X 1.25 X 20 3
Y 23 200370019 WASHER, M8.4 LOCK 4
Y 24 32491 WASHER, 5/16 FLAT 4
Y 25 606672 SCRUBBER HEAD, CYL BRUSH,
610MM (24 IN)
1
Y 26 222179 BRACKET, ROLLER 2
Y 27 16931 SCREW, HEX M8 X 1.25 X 20 2
Y 28 222178 DROLLER, WALL 2
Y 29 222196 PIN, CLEVIS, .5 DIA, 4.25 LG 2
Y 30 578421 PIN, COTTER, 1/8X1 2
Y 31 606225 DHOSE, 1/2” ID 1
∇ ASSEMBLY / CONJUNTO / ENSEMBLE
Y INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA / Y COMPRIS EN
ENSEMBLE
D RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
ELÉMENTS DE STOCK RECOMMANDÉS
REF PART # DESCRIPTION QTY.
Y 32 608964 BOOT, TERMINAL BLACK 4
Y 33 222210 DPIN CLEVIS, .62 DIA X 2.12 L 2
Y 34 15678 SCREW, M6X1X16 HEX 4
Y 35 222182 DBAR, SUPPORT 4
Y 36 79506 SCREW, M8X1.25X30 FLAT 8
Y 37 223566 DBRACKET, SHIELD 2
Y 38 223569 DGASKET, SHIELD 2
Y 39 606569 BRACKET, T--FITTING, SCRUB-
HEAD
1
Y 40 222536 DTEE, FITTING, BARB 1
Y 41 608176 DHOSE, REINFORCED 1/2ID 1
Y 42 606674 DCONNECTOR, UNION .5X.5 1
Y 43 16931 SCREW, HEX M8 X 1.25 X 20 1
Y 44 200370019 WASHER, M8.4 LOCK 1
Y 45 32491 WASHER, 5/16 FLAT 1
Y 46 605050 SCREW, 3/8--16X2.75 1
Y 47 140022 WASHER, 3/8 LOCK 1
Y 48 140046 WASHER, 1.00X.392X0.90 1
Y 49 00954 DKEY, SQUARE, .12X.12X1.0LG 2
Y 50 630447 DWASHER, NYLON, 12.7, 25.4 2
Y 51 200370019 WASHER, M8.4 LOCK 2
Y 52 200662017 WASHER, LOCK, 6.4ID 4
Y 53 140000 WASHER, 1/4 FLAT 4
Y 54 3147 DNUT, HEAVY HEX JAM 5/8--11 1
Y 55 606548 DSTUD, ADJUSTER 1
Y 56 200031499 SCREW, M8X1.25X40 1
Y 57 140314 CLAMP, CABLE INSULATED 3/4ID 1
Y 58 069767163 SPACER, 1X.75 1
Y 59 578717 SCREW, M8X1.25X50 2
Y 60 07786 NUT, M8 HEX 2
Y 61 02942 DPIN, HAIR, CTR, .62D .12 WIRE 2
Y 62 6306.4 WASHER, 1/4 FLAT 4
Y 63 200370019 WASHER, M8.4 LOCK 4
Y 64 32491 WASHER, 5/16 FLAT 2
Y 65 604317 DELBOW, 90° 1/2” ID 1
