Operator`s manual

Kerosene Portable Heaters Manual 9
PORTABLE HEATER SPECIFICATIONS
WIRING DIAGRAM
Model MH-0125-0MIH MH-0300-0MIH
Rating BTU/Hr 125,200 288,700
Fuel Consumption
Gal/Hr
0.883 2.04
Fuel Tank Capac-
ity Gallons
14.0 36.0
Pump Pressure
PSI
175 175
Volt/Hz 115V / 60 Hz 115V / 60 Hz
Amps 7.0 12.5
Phase Single Single
Size (L x W x H) 47" x 24" x 31" 68" x 29.5" x 40.4"
Net Weight (Lbs) 154 282
Nozzle Size (gph) 0.65 1.50
TH
IN
FC
EV
M
black
green
green
black
white
PL
TR
white
EV
TR
M
L
N
FR
TRcont.
FC
PL
TH
IN
PL
black
black
black
white
white
L
N
FR
SL
green
white
red
black 1
black 2
dk. blue
lt. blue
brown
M13
M17
M15
M9
M7
M11
M18
M16
M14
M12
M10
M8
M19M4
M3
M2M1M6M5
FS
2
1
3
1
3
2
Optional
PL
brown
black
PA
P
black brown
EV Fuel Solenoid Valve
TR Ignition Transformer
M Motor
SL Warning Lamp
PA Air Pressure Switch
FS Fuse
FC Flame Sensor
PL Reset Button
IN Switch
TH Remote Thermostat
FR Heated Filter
