Operating instructions

8 58D6002


NOTE: Anexternalregulatorisrequiredtoreducesupplypressuretoamaximumof10
1
/2"w.c.onNaturalGas
systemsoperatingathigherpressure.

Regulator Pressure Setting: 3.5" w.c.
Pilot Regulator: 3.5" w.c.
Gas Inlet Pressure: Max. 10 1/2" w. c. Min. 5" w.c.

Piezo ignitor allows ignition of the pilot without the use of matches.
 
 - All gas to the burner is shut off at the valve.
 - Valve position to light/maintain a standing pilot.
 - Valve position to turn burners ON/OFF with remote switch.
 - Variable position to control flame height (heat output). Both front and rear burners are in
operation to provide realistic glow and yellow flame.
PILOT/ODS
The gas log heater is fitted with a specially designed safety pilot (ODS assembly) light which senses the amount
of oxygen available in the room and shuts the gas log heater off if the oxygen level begins to drop below a satis-
factory level. The pilot can only be relit when adequate fresh air is available.

The millivolt gas log pilot is fitted with a millivolt thermopile generator to provide power for remote activation.

Note: Anexternalregulatorisrequiredtoreducesupplypressuretoamaximumof13"w.c.

Regulator Pressure Setting: 10" w.c.
Gas Inlet Pressure: Maximum 13" w.c.
Minimum 11" w.c.
 

 
CSVF20SNVVFCS20DNV (G-EBL-ES-EMB)
CSVF30SNVVFCS30DNV (G-EBL-ES-EMB)
Millivolt
Millivolt
10,000
32,000
6,000
20,000
 

 
CSVF20SPVVFCS20DPV (G-EBL-ES-EMB)
CSVF30SPVVFCS30DPV (G-EBL-ES-EMB)
Millivolt
Millivolt
10,000
32,000
6,000
20,000
