In addition, periodically check the flames visually during operation.

It should just touch the top of the
thermocouple tip for natural. SeeFigure17for correct pilot flame.
If the pilot flame does not touch the thermocouple, then the burners cannot function reliably. SeeFigure18for
incorrect shape of pilot flame.

Figure 17 - Correct Appearance of Pilot Flame
Figure 18 - Incorrect Appearance of Pilot Flame
Thermocouple
for Natural
Thermocouple
for LP
Thermocouple
for LP
Thermocouple
for Natural

