- User Instructions for the Micromat boiler
- Product Description
- Technical Data
- Delivery Consignment / Unpacking the boiler
- Boiler location
- Installation Clearances
- Wall Mounting
- Gas Connection
- Gas Conversion
- System Flow & Return connections
- Condensate Connection
- Flue / Combustion Air connection
- Flue Systems
- Calculating Flue Resistance
- Ventilation requirements single appliances
- Hydraulic System Design
- System type 1
- System type 2
- System type 3
- System type 4
- System type 5
- System type 6
- System type 7
- System type 8
- Water Treatment
- Soldering Flux
- Electrical Connection
- System Type 1
- System Type 2
- System Type 3
- System Type 4
- System Type 5
- System Type 6
- System Type 7
- System Type 8
- Commissioning The Micromat EC
- Installation Codes
- First Firing
- Pop Up Menu
- Setting DHW Temperature
- Servicing
- Screen Display Diagnosis of Faults
Energy Technology
Ltd.
7
EngineerEngineer
EngineerEngineer
Engineer
s Buttons Button
s Buttons Button
s Button
The user will not normally need to use this button. It is used by the service technician to enable measurement of
flue emissions even without heat requirement being present.
NOTE: This function will not be available if the MICROMAT EC and the heating system have reached their maximum
temperatures.
If the Engineers button is pressed once then the MICROMAT EC operates with half power. The display shows [Flue
Emissi]. If the Engineers button is not pressed again within 10 minutes the MICROMAT EC will switch back to
automatic operation after this period. Pressing the button again when [Flue-Emissi] is displayed brings [10min Low]
onto the display. In this condition the power output of the boiler can be adjusted using the ‘+’ and ‘-’ keys
Pressing the ‘-’ key will reduce the power & pressing the ‘+’ key will increase power.
Pressing the Engineers button again while [10 min. low] is shown in the display switches the MICROMAT EC back
to automatic operation. After 10 minutes partial output the MICROMAT EC will return to automatic operation
TEST ButtonTEST Button
TEST ButtonTEST Button
TEST Button
The Test button is used to simulate the operation of the hot water high limit stat.
Whilst theTEST-button is pressed the display shows [Limit F/R W/D]. During this display the function of the
MICROMAT EC is blocked. When the button is released the boiler will return to normal operation.
If the button is pressed for more than 3 minutes [STB-Supply] will blink on the display. The function of the MICROMAT
EC is then locked.
The MICROMAT EC can also be locked more quickly by simultaneously pressing the TEST and ENGINEERS button.
When the RESET button is pressed again the MICROMAT EC returns to automatic operation.
