18.3 first
firing
h)Check CO2% of heat exchanger and adjust as necessary screw (4) Q max of right hand valve, to obtain required
value. (See table I)
NOTE: Adjustment of either (3) Q min or (4) Q max will affect the other adjustment to a lesser or greater extent.
Following either adjustment of (3) or (4) check the effect on the setting of the other adjustment and correct as
necessary.
i)Remove analyser from upper heat exchanger and refit cap/plug to test point.
j)Press Engineer ‘s test button once to exit 10 minute test mode.
k)Turn off electricity and gas supplies and remove manometer from inlet pressure test point and refit test point
screw.
l)Turn on gas and electricity supplies.
