Technical data

46
18.2 installation
codes
Flow temperature control(without room controller and without weather
compensation) without DHW sensor or with DHW control via thermostat and
three way valve
Low Temperature heating 30
Medium Temperature heating 31
High Temperature heating 32
Medium Temperature heating 33
High Temperature heating 34
without mixing circuit
(Direct heating only )
Without outside temperature sensor, room unit, room thermostat
(Fixed point control)
Direct Heating and
mixing c ircuit with MR03
(the mixing circuit is
always low temperatue
heating)
Without outside temperature sensor, room unit, room thermostat
(Fixed point control)
Cascaded boiler installation without DHW sensor or with DHW control via
thermostat and three way valve
Max heating temperature is set in
the KKM
35
Max heating temperature is set in
the cascade controller
36
MAN Kaskade manager(KKM) with PWM s ignal. (Connected t o R2 and R3)
Other cascade controller with 0 - 3V output signal (connection to ...)
Weather compensated control with DHW sensor and pumped DHW circuit.
Low Temperature heating 37
Medium Temperature heating 38
High Temperature heating 39
Low Temperature heating 40
Medium Temperature heating 41
High Temperature heating 42
Low Temperature heating 43
Medium Temperature heating 44
High Temperature heating 45
Medium Temperature Direct heating 46
High Temperature Direct heating 47
Medium Temperature Direct heating 48
High Temperature Direct heating 49
Medium Temperature Direct heating 50
High Temperature Direct heating 51
Medium Temperature Direct heating 52
High Temperature Direct heating 53
Weather Compens ated
Direct Heating and
mixing c ircuit (the mix ing
circuit is always low
temperatue heating)
with two RE2132 Room Units
with one RE2132 Room Unit
with Room Thermostat
without room unit or thermostat or with RE2 room regulat or
Weather Compens ated
Direct Heating without
mixing circuit (direct
heating only )
with RE2132 Room Unit
with Room Thermostat
without room unit or thermostat or with RE2 room regulat or
