15.0 ventilation requirements
single appliances
Table 6 Compartment Installation - Room Sealed Flue
Natural Ventilation Direct to Outside Air
Boiler Model Ventilation openings Free Area cm
2
High Level Low Level
Micromat EC 16/22 110 110
Micromat EC 24/28 140 140
Micromat EC 31/36 180 180
Micromat EC 38/45 225 225
Table 7 Compartment Installation - Room Sealed Flue
Natural Ventilation from Adjacent room
Boiler Model Ventilation Openings Free Area cm
2
High Level Low Level
Micromat EC 16/22 220 220
Micromat EC 24/28 280 280
Micromat EC 31/36 360 360
Micromat EC 38/45 450 450
