Single-Line Laser Scan Engine Integration Guide
Table Of Contents
- IS4813, IS4815, IS4823 and IS4825
- Copyright/Trademarks
- Table Of Contents
- Introduction
- Assembly
- Mounting Specifications
- IS4813 and IS4815 Scan Engine Dimensions
- IS4823 and IS4825 Bracketed (-1 and -2) Dimensions
- IS4823 and IS4825 (-0) Decode Printed Circuit Board Dimensions
- Exit Beam Specifications
- Enclosure Specifications
- Electrostatic Discharge (ESD) Cautions
- Grounding
- Power Supply
- Power Sequencing
- Flex Cables
- Thermal Considerations
- Printed Circuit Board (PCB) Component Clearance
- Magnetic Sensitivity
- Airborne Contaminants and Foreign Materials
- Beam Clearance
- Output Window Properties
- Output Window Coatings
- Output Window Angle
- Minimum Allowable Window Position RequiredTo Avoid Detrimental Internal Reflective Beam Interference at Positive Exit Beam Angle Tolerance
- Minimum Allowable Window Position Required To Avoid Detrimental Internal Reflective Beam Interference at Negative Exit Beam Angle Tolerance
- Scan Engine Field Of View And Depth Of Field
- Descriptions Of IS4823 AND IS4825 Operating Modes
- Serial Configuration Mode
- General Design Specifications
- Detailed Electrical Specifications
- Scan Engine Terminations
- Decode Printed Circuit Board Terminations
- Flex Cable Specifications And Installation Guidelines
- Timing Diagrams
- Bar Code Element Time Calculation
- Regulatory Compliance
- Limited Warranty
- Patents
- Index
- Contact Information
- MANUAL DATE CODE
2
Models and Accessories
Non-Decode Engines
Options
Model Description
IS4813 Non-Decode, 3.3VDC Scan Engine
IS4815 Non-Decode, 5VDC Scan Engine
Accessories
Part Number Description
19-07335 Flex Cable, 10-POS, 67.5 mm Length
Decode Engines
Options
Base Model Description
IS4823 3.3VDC Scan Engine with Decode PCB
IS4825 5VDC Scan Engine with Decode PCB
Model and Kit Delineation
Figure 1. IS4823/IS4825 Model and Kit Delineation
Accessories
Part Number Description
19-00329 Flex Cable, 12-POS, 80 mm Length
19-07335 Flex Cable, 10-POS, 67.5 mm Length
Labels
Figure 2. Serial Number Label (Enlarged For Illustration Purposes)
† Option is not available for sale in all regions. Contact a customer service representative for additional information.
