22
Electrical
IS4813 IS4815
Input Voltage: 3.3VDC ± 0.3VDC 5.0VDC ± 5%
Power Consumption: 400 mW 350 mW
Typical Operating Current: < 120 mA @ 3.3VDC < 70 mA @ 5.0VDC
Standby Current: < 30 mA @ 3.3VDC < 15 mA @ 5.0VDC
IS4823 IS4825
USB TTL USB TTL, RS232
Peak Operating Current: 170 mA 150 mA 135 mA 135 mA
Idle Current: 75 mA 50 mA 72 mA 45 mA
Sleep Current: 65 mA 5.5 mA 53 mA 15 mA
Suspend Current (USB): 5.5 mA N/A 0.30 mA N/A
Power Down Current
(TTL):
5.5 mA 15 mA
See pages 33 - 36 for regulatory compliance information.
Environmental
Operating Temperature: -0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5% to 95% relative humidity, non-condensing
Vibration Protection: 7G over 10 – 500 Hz
Specifications are subject to change without notice.
