General Design Specifications
Operational
Light Source: Visible Laser Diode (VLD) @ 650 nm
Laser Power: 1 mW
Depth of Scan Field: 50 mm – 254 mm (2" – 10") for 0.33 mm (13 mil) bar codes
57 mm (2.2") @ 50 mm (2") from engine face
Width of Scan Field:
264 mm (10.4") @ 254 mm (10") from engine face
Scan Speed: 100 Scan Lines per Second Typical
Scan Pattern: Single Scan Line
Minimum Bar Width: 0.10 mm (4.0 mil)
IS4813 and IS4815 Software Dependent
Symbologies Supported:
IS4823 and IS4825 Autodiscriminates All Standard 1D Symbologies
System Interface: IS4823 and IS4825 USB, TTL RS232
Print Contrast: 35% Minimum Reflectance Difference
IS4813 and IS4815 Decode Dependent
Number of Characters
Read:
IS4823 and IS4825 Up to 80 data characters (Maximum)
Roll, Pitch, Yaw 42°, 68°, 52°
Mechanical
Dimensions: See pages 6 – 8 for detailed specifications.
IS4813 / IS4815 Non-Decode Engine 8 g (0.282 oz)
IS4823 / IS4825 Bracketed (-1) Assembly 15 g (0.529 oz)
Weight (Maximum):
IS4823 / IS4825 Non-Bracketed (-1) Assembly 10 g (0.353 oz)
IS4813 / IS4815 Non-Decode Engine 10-PIN ZIF Connector
Termination:
IS4823 / IS4825 Decode PCB 12-PIN ZIF Connector
Enclosure and
Mounting:
See pages 6 – 13 for detailed specifications on enclosure and
mounting guidelines.
Specifications are subject to change without notice.
