2.1. Keypad
765 Dosimat
4
2 Operation with the keyboard
2.1 Keypad
6.2149.000
SMPL
9
BLANK
7
FACTOR
8
RATE VOLUME EXP
ENTER
FILL
GO CLEAR
RECALL
6
STORE
5
UNIT
4
3
2
1
MODE
–
.
0
RATE Expelling and filling rate in all modes.
VOLUME Different volumes depending on selected
mode.
EXP Exponent.
BLANK
FACTOR Calculation parameters in mode DOS.
SMPL
UNIT Unit in modes DOS and CNT
STORE Management of user memory:
RECALL Storing, loading of modes.
MODE Selection of mode.
ENTER Confirmation of entries.
FILL Filling and emergency stop key.
CLEAR Resetting of the volume display to 0 with
Dosimat in stand-by position.
GO Start mode. With mode DOS, dosing
goes on as long as <GO> is pressed.
The keys <FILL>, <CLEAR>, <GO> are identical
with the corresponding keys on Dosimat.
