2.3 User memory
765 Dosimat
17
2.3 User memory
Up to 10 modes, complete with their user selected specific parameters, can be stored in
the user memory.
The relation of the different memories is shown in the following table:
<MODE> <STORE>
<RECALL>
Management of user memory
<STORE><X><ENTER>
Storing a mode at address X
(X=0,1,...9)
<RECALL><X><ENTER>
Loading a mode from the user memory into the working
memory.
Ex factory, the standard modes are stored in the user
memory.
Fixed memory
contains:
modes with standard
parameters:
DOS
DIS R
DIS C
PIP
DIL
CNT D
RECALL
6 5
STORE
5
STORE
Working memory
contains:
1 mode; parameters can
be modified
User memory
contains:
up to 10 user modes
