2.2 Modes
765 Dosimat
7
Example:
Selection of mode "DIS C", cumulative dispensing.
Press <MODE>.
Display shows that mode which has been selected last with key <MODE>, e.g.
DOS .
Press <MODE> repeatedly until display shows DIS C .
Load mode "DIS C" into working memory with <ENTER>.
Display shows DIS C 0.000 ml.
Mode "DIS C" is ready to work, the piston is in zero position.
All modes which are loaded into the working memory by key <MODE> are equipped
with a set of standard parameters:
Mode V-DIS/V-PIP
mL
V-LIM/V-DIL
mL
Rate
↑
mL/min
Rate ↓
mL/min
Calculation
DOS – OFF OFF max. b=0; f=1; s=1
DIS R 1 – OFF max. –
DIS C 0.1 OFF OFF max. –
PIP 0.1 – OFF OFF –
DIL 0.1 1 OFF OFF –
CNT D – – OFF max. –
2.2.1 Mode DOS, Dosing
Dosimat is dosing as long as <GO> is pressed. Result calculation can be activated.
V-LIM OFF ml
Security volume:
Dosing is stopped if V-LIM has been reached.
Input range: 0.001...999.999 mL, OFF
Expelling and filling rate, see page 6.
VOLUME
RATE
