4.5 Methods
■■■■■■■■■■■■■■■■■■■■■■
58
■■■■■■■■
743 Rancimat
Renaming an existing method
Proceed as follows to rename an existing method:
Note
A method which is still selected in one of the blocks A or B, cannot be
renamed. Select another method first in order to rename the required
method.
1
Open Method manager
■ In the Control window, click on the symbol
or the menu
item File ▶ Method manager....
The following dialog window appears:
2
Select and rename method
■ Click on the required method and then the button [Rename].
The method name is highlighted in blue.
■ Enter the new method name and click with the mouse on the free
white area below the method name in order to accept the
change.
■ Click on the [Close] button.
Saving a method under a new name
Proceed as follows to save an existing method under a new name:
1
Open method
■ In the Control window, click on the symbol
or the menu
item File ▶ Open method....
The dialog window Open method appears.
■ Click on the required method and confirm the selection with
[Open].
