4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
57
Opening a selected method and adjusting parameters
Proceed as follows to open the method which is selected in the Control
window and adjust its parameters:
1
Open method
￭ In the Control window, click on the symbol in the required
Block A or B.
The dialog window "Method name" appears.
2
Adjust parameters and save changes
￭ Adjust the parameters (see Chapter 4.5.2, page 60).
￭ Confirm the changes with [Save].
Opening an existing method and adjusting parameters
Proceed as follows to open an existing method and adjust its parameters:
1
Open existing method
￭ In the Control window, click on the symbol
or the menu
item File ▶ Open method....
The dialog window Open method appears.
￭ Click on the required method and confirm the selection with
[Open].
The dialog window "Method name" appears.
2
Adjust parameters and save changes
￭ Adjust the parameters (see Chapter 4.5.2, page 60).
￭ Confirm the changes with [Save].
