4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
51
1
3
4
5
6
7
8
9
2
9
10
Figure 6 Equipping the reaction vessel for determining Delta T
1
FEP tubing 250 mm (6.1805.080)
For supplying air into the reaction vessel.
2
Pt100 temperature sensor
3
Thread adapter M8 / M6 (6.1808.090)
4
Opening for temperature sensor
For inserting the temperature sensor.
5
Air tube
6
O-ring (6.1454.040)
7
Connector
For connecting the thread adapter M8 / M6.
8
Reaction vessel cover (6.2753.107)
9
Spacer (6.2042.040)
10
Reaction vessel (6.1429.040)
