4.3 Program information
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
46
￭￭￭￭￭￭￭￭
743 Rancimat
Note
You can find the meaning of the symbols and columns in the
event overview at "Meaning of the symbols and columns in the
event overview", page 47.
2
Update view
￭ Click on the symbol or the menu item View ▶ Refresh to
view the current status of the log file.
3
Save log file
￭ Click on the symbol or the menu item File ▶ Save as….
￭ In the dialog window Save file as enter a file name and confirm
with [OK].
4
Open saved log file
￭ Click on the symbol
or the menu item File ▶ Open….
￭ In the dialog window Open, select the required file and confirm
with [OK].
Filtering entries in the event overview
Proceed as follows to filter the entries in the event file:
1
Filter the entries
￭ Click on the required filter criterion (e.g.: date = "30.08.2006").
