Owner's manual
Table Of Contents
- Table of contents
- Table of figures
- 1 Introduction
- 2 Overview of the instrument
- 3 Installation
- 4 Operation
- 4.1 Fundamentals of operation
- 4.2 Instrument and Program Settings
- 4.3 Program information
- 4.4 Calibration functions
- 4.5 Methods
- 4.6 Determinations
- 4.6.1 Preparing samples
- 4.6.2 Preparing the instrument and the accessories
- 4.6.3 Preparing the determination
- 4.6.4 Starting the determination
- 4.6.5 Cleaning the instrument and accessories
- 4.6.6 Adjusting the method parameters during the determination
- 4.6.7 Stopping the determination manually
- 4.6.8 Status of the live curve
- 4.7 Results
- 4.8 GLP functions
- 5 Handling and maintenance
- 6 Troubleshooting
- 7 Technical specifications
- 8 Conformity and warranty
- 9 Accessories
- Index

■■■■■■■■■■■■■■■■■■■■■■
4 Operation
743 Rancimat
■■■■■■■■
45
Sample ID1
Sample identification 1.
Status
Status of the channel.
ready: No active measurement. The channel is ready for starting a deter-
mination.
running: Instrument is measuring.
finished: Determination finished. The channel is ready for starting a new
determination.
error: Communication error between instrument and PC.
Stab. time
Stability time determined.
Induc. time
Induction time determined.
Set temp.
Setpoint temperature (defined in the method).
Current temp.
Current block temperature.
4.3.3 Displaying, filtering and deleting event overview
Opening and saving the event log file
Proceed as follows to display and save all events of the Rancimats connec-
ted to the PC:
1
Open current log file
■ In the Control window, click on the menu item View ▶ Event
log overview.
The following dialog window appears:
