Owner's manual
Table Of Contents
- Table of contents
- Table of figures
- 1 Introduction
- 2 Overview of the instrument
- 3 Installation
- 4 Operation
- 4.1 Fundamentals of operation
- 4.2 Instrument and Program Settings
- 4.3 Program information
- 4.4 Calibration functions
- 4.5 Methods
- 4.6 Determinations
- 4.6.1 Preparing samples
- 4.6.2 Preparing the instrument and the accessories
- 4.6.3 Preparing the determination
- 4.6.4 Starting the determination
- 4.6.5 Cleaning the instrument and accessories
- 4.6.6 Adjusting the method parameters during the determination
- 4.6.7 Stopping the determination manually
- 4.6.8 Status of the live curve
- 4.7 Results
- 4.8 GLP functions
- 5 Handling and maintenance
- 6 Troubleshooting
- 7 Technical specifications
- 8 Conformity and warranty
- 9 Accessories
- Index
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
27
Options Carry out general settings, set instrument config-
uration, manage access rights.
Help Call up program-specific Online help.
Symbols
New method
Create a new method (see Chapter 4.5.1, page 55).
Open method
Open an existing method (see Chapter 4.5.1, page 55).
Method Manager
Open, rename and delete methods (see Chapter 4.5.1, page 55).
Print
Print results (see Chapter 4.7.6, page 128).
Results Open Results window (see "Opening and closing the Results window", page
28).
Live parameters Display live parameters which can be changed for a current determination (see
Chapter 4.6.6, page 84).
Status overview Display status overview for the instruments connected (see Chapter 4.3.2, page
44).
Instrument informa-
tion
Instrument information (see Chapter 4.3.1, page 42).
GLP status
Display GLP status (see Chapter 4.8.3, page 144).
Instrument 1…4
Select instrument 1…4.
Start all channels
Block A
Start all channels of Block A (see Chapter 4.6.4, page 83).
Start all channels
Block B
Start all channels of Block B (see Chapter 4.6.4, page 83).
Help topics
Call up the Online help.
4.1.4 Results window
The dialog window 743 Rancimat Results serves for displaying, output-
ting and recalculating results of the determinations recorded with the 743
Rancimat. The determination data is saved in database files *.mrd and
can be displayed in this dialog window in the form of overview tables and
curves. The Results window can also run if the Control window is closed.
