9 Accessories
743 Rancimat
￭￭￭￭￭￭￭￭
187
Order no. Description
Set of 100 pieces. In combination with 6.1429.050.
Material: Glass
Outer diameter (mm): 4
Inner diameter (mm): 2.4
Length (mm): 248
6.2757.000 Air collection tube for stability instruments
Including 8 stoppers.
Outer diameter (mm): 30
Length (mm): 367
6.2821.090 Aspiration filter
Pore size 20 µm, set of 5 pieces. For 6.1834.000 aspiration tubing and
6.1821.040 and 6.1821.050 filter tubes.
Material: PE
Outer diameter (mm): 9.5
Length (mm): 35.5
6.5616.000 GLP Test Set
GLP test set for the exact adjustment and validation of temperature on 743 Ran-
cimat and 763 PVC Thermomat. Consists of:
6.1111.010: Pt100 temperature sensor
6.1253.000: Measuring insert for temperature sensor
6.2042.040: Clamp for temperature sensor
6.2109.030: Plug with resistor
6.2418.000: Air tube for oil measurements
6.2621.120: Hexagon key 1.5 mm
6.9987.431 Validation Documentation for 743 (German)
6.9987.433 Validation Documentation for 743 (English)
