9 Accessories
743 Rancimat
￭￭￭￭￭￭￭￭
185
9.2 Optional accessories
Order no. Description
2.145.0320 Port extension USB - 4xDB9
For connection (DB9) of 4 additional instruments to the USB interface of the
computer (WIN98, 2000 or XP).
6.1111.010 Pt100 Temperature sensor
Pt100 temperature sensor for 711 Liquino and 6.5616.000 GLP test set for sta-
bility measuring instruments.
Shaft material: Stainless steel (AISI 304)
Measuring range: -200 ... 300
Measuring unit: °C
Shaft diameter top (mm): 2
Shaft diameter bottom (mm): 2
Shaft length to head (mm): 178
Min. immersion depth (mm): 20
Temperature sensor: Pt100
6.1428.030 Glass measuring vessel for stability measurements
Conductivity measuring vessel made of clear glass for 873 Biodiesel Rancimat,
743 Rancimat and 763 PVC Thermomat.
Material: Clear glass
Height (mm): 91
Outer diameter (mm): 46
6.1429.050 Reaction vessel long for stability measurements
Reaction vessel for stability measurements involving volatile oils, mineral oils and
biodiesel blends with 743 Rancimat and 873 Biodiesel Rancimat. In combination
with 6.2418.130. Set of 100 pieces.
Material: Clear glass
Outer diameter (mm): 24
Length (mm): 250
