9.1 Scope of delivery
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
182
￭￭￭￭￭￭￭￭
743 Rancimat
Qty. Order no. Description
24 6.1816.010 Silicone tubing 0.22 m
Connection tubing for stability measuring instruments.
Material: Silicone rubber
Outer diameter (mm): 9
Inner diameter (mm): 6
Length (mm): 220
8 6.1819.080 Cannula for gas feeding
For stability measuring instruments.
Material: PTFE
Outer diameter (mm): 4
Inner diameter (mm): 3
Length (mm): 85
1 6.1821.040 Filter tube
Filter tube for 6.1608.050 drying bottle. For Rancimats and Karl
Fischer ovens.
Length (mm): 112
1 6.2041.190 Holder for reaction vessels
Reaction vessel holder for stability instruments; for 8 reaction vessels.
Material: Aluminum
Width (mm): 170
Height (mm): 110
Depth (mm): 110
