4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
137
Definition for multiple graph printing
with offset
on | off (Default value: off)
If this option is activated, the curves are arranged with an offset above
one another in the case of an output of multiple graphs. Instead of the
usual lettering of the conductivity axis, the difference of the entire axis is,
in this case, printed in µS/cm.
"Company settings" tab
On the Company settings tab, you can carry out the settings for the
output of company logo and company text in the header.
[Company-logo…]
Open the window Find company logo for selecting the graphics file
with the company logo. Only WMF or BMP files can be used. After click-
ing on [Open], the logo is displayed in the adjoining window.
[Remove logo]
Remove the embedded company logo.
Logo on the...
Selection
left side | right side
left side
The company logo is printed out on the left edge of the header.
right side
The company logo is printed out on the right edge of the header.
Company text
The text entered here is printed out on the side of the header opposite the
company logo.
Input
Characters
