4 Operation
743 Rancimat
■■■■■■■■
135
■ Open the required database by entering the previously read out
password.
Exporting the measured value list
Proceed as follows to export a list of all measured values to a TXT file:
1
Display determination overview
■ See "Displaying the determination overview", page 87.
2
Select determination
■ Select the determination of which the data is to be exported (see
"Selecting determinations", page 90).
3
Export data
■ Click on the symbol
or the menu item Determina-
tion ▶ Export ▶ List of measured values.
The dialog window Save to export file appears.
■ Select the memory location, enter the file name and confirm with
[Save].
The measured values list will be exported.
4.7.7 Program settings
Carrying out settings for the representation and output of
results
You can carry out settings for the representation and output of results as
follows:
1
Open dialog window
■ In the Results window, click on the menu item Options ▶ Set-
tings.
2
Carry out settings
■ See the following "Report settings" tab.
