4.7 Results
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
134
￭￭￭￭￭￭￭￭
743 Rancimat
4
Keep or delete determination
￭ Click on [No] to also keep the exported determination in the
original database.
￭ Click on [Yes] to delete the exported determination in the origi-
nal database.
Opening the database in Microsoft Access 97
Note
Each database is password-protected. The password is generated auto-
matically by the program and can only be read by the Administrator.
The databases are saved in the installation directory of the 743 Ranci-
mat program at C:\Program Files\Metrohm\Rancimat\Database.
1
Open Results window
￭ In the Control window, click on the symbol
or the menu
item File ▶ Results....
The Results window appears.
2
Read out database password
￭ In the Results window, click on the menu item
Options ▶ Administrator ▶ Database password.
The dialog window Open appears.
￭ Select the required database and confirm with [Open].
The dialog window Password appears with the password for the
previously selected database.
3
Open database in Microsoft Access 97
￭ Start Microsoft Access 97.
