4.7 Results
■■■■■■■■■■■■■■■■■■■■■■
132
■■■■■■■■
743 Rancimat
Printing extrapolation results
Proceed as follows to print the extrapolation graph (normal and
detailed view), the extrapolation results and the overview of the deter-
minations used for the extrapolation with the fields ID 1, ID 2, tempera-
ture and result:
1
Display extrapolation results
■ See "Extrapolation of several results", page 118.
2
Print extrapolation results
■ Click on the symbol
or the menu item File ▶ Print....
The dialog window Print appears.
■ Select the required printer and click on [Print].
The extrapolation results will be printed.
Exporting the determination overview to Word or Excel
Proceed as follows to export the determination overview to Word or
Excel:
1
Select determinations
■ See "Selecting determinations", page 90.
If you do not select any determinations, the entire overview is
exported.
2
Select export program
■ Click on the symbol
or the menu item Determina-
tion ▶ Export ▶ Export to MS Word.
The data is copied to a RTF file to be opened automatically by
Microsoft Word.
or
■ Click on the symbol
or the menu item Determina-
tion ▶ Export ▶ Export to MS Excel.
Microsoft Excel will be opened automatically.
