4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
131
￭ Select the option Determination according to method and
confirm with [Print].
The dialog window Print appears.
4
Print report
￭ Select the required printer and click on [Print].
The report will be printed.
Printing the report defined under "Settings"
Proceed as follows to print the report of one or several determinations,
which has been defined under Settings:
1
Display determination overview
￭ See "Displaying the determination overview", page 87.
2
Select determination
￭ Select the determination of which the report is to be printed (see
"Selecting determinations", page 90).
3
Select data
￭ Click on the symbol
or the menu item File ▶ Print....
The dialog window Printing of... appears.
￭ Select the option Determination according to settings.
4
Carry out settings
￭ Click on the [Settings] button.
The dialog window Program settings appears.
￭ Carry out the required settings (see tab "Report settings", page
136) and confirm with [OK].
The dialog window Printing of... appears.
5
Print report
￭ Click on the [Print] button.
The dialog window Print appears.
￭ Select the required printer and click on [Print].
The report will be printed.
