4 Operation
743 Rancimat
■■■■■■■■
129
■ Select the required determinations and click on [Print].
The results are printed according to the settings which have been
defined in the method on the tab Documentation.
Printing determination overview
You can print a determination overview either in the form of a table or a
list. Proceed as follows:
1
Display determination overview
■ See "Displaying the determination overview", page 87.
2
Select type of output (table or list)
■ Click on the symbol
or the menu item File ▶ Print....
The dialog window Printing of... appears.
■ Click on the option Overview table and/or Overview list.
Note
In the overview table, only those columns are printed which are
within the maximum print width (15 cm).
3
Print determination overview
■ Click on the [Print] button.
The dialog window Print appears.
■ Select the required printer and click on [Print].
The determination overview will be printed.
Printing determination and method data
Proceed as follows to print the determination and method data of one or
several determinations:
1
Display determination overview
■ See "Displaying the determination overview", page 87.
2
Select determination
■ Select the determination of which the data is to be printed (see
"Selecting determinations", page 90).
