4 Operation
743 Rancimat
￭￭￭￭￭￭￭￭
123
Recalculating formulas
Proceed as follows to recalculate the results of the formulas:
1
Open dialog window
￭ Select the determination which is to be recalculated (see "Select-
ing determinations", page 90).
￭ Click on the menu item Determination ▶ Recalculation.
The dialog window Recalculation appears.
￭ Click on the tab Formulas.
2
Adjust the parameters
￭ Activate the options Recalculate formula 1 for induction
time and Calculation active.
or
Activate the options Recalculate formula 2 for stability time
and Calculation active.
or
Activate the options Recalculate formula 3 for stability time
and Calculation active.
￭ Re-enter the parameters for the formula and confirm with [OK].
Note
A detailed description of the parameters can be found at "Recalcu-
late formula 1 for induction time", page 126.
Recalculating the standard time
Proceed as follows to recalculate the standard time:
1
Open dialog window
￭ Select the determination which is to be recalculated (see "Select-
ing determinations", page 90).
￭ Click on the menu item Determination ▶ Recalculation.
The dialog window Recalculation appears.
￭ Click on the tab Standards.
2
Adjust the parameters
￭ Activate the options Recalculate standard time and Calcula-
tion active.
