4 Operation
743 Rancimat
■■■■■■■■
119
3
Update the display
■ Click on the [Update] button.
The graph and all results are updated.
Note
For extrapolation of the induction times, the manually changed
values of the selected determinations (if present) are used, other-
wise the automatically determined values are used.
Setting the correlation limit
Note
The correlation limit for the correlation coefficient r
2
can only be set
by an Administrator.
1
Open dialog window
■ In the Results window, click on the menu item
Options ▶ Administrator ▶ Extrapolation parameter.
The following dialog window appears:
2
Adjust limit
■ Under correlation limit (r
2
) enter a value between 0 and 1 and
confirm with [OK].
Copying a graph and pasting it into other programs
See "Copying graphs and pasting them into other programs", page 115.
Printing extrapolation results
See "Printing extrapolation results", page 132.
