4.4 Sample changer
One or two sample changers (if connected) can be operated from the
sample changer window which is accessed with the [Sample changer]
softkey on the ‘Manual control page’.
ÚÄÄÄ Devices & Manual Control ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ÚÄÄÄ Sample changer ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿ ³
³ Do³ ³ ³
³ ³ Changer 1: ready [000001] 2: not available ³ ³
³ Do³ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ³ ³
³ Re³ Rack type/name M12-0 - 12*250mL ³ ³
³ Ko³ Max. beakers 12 ³ ³
³ Bü³ ÚÄÄÄÄÄÄÄÄÄÄÄ¿ ³ ³
³ Bü³ Tower ³ 1 ³ 2 ³ ³
³ Ko³ Lift pos.[mm] ³ 0 ³ 0 ³ ³
³ Do³ Beaker pos. ³ 1 ³ 12 ³ ³
³ÄÄij Beaker found ³ yes ³ no ³ ³
³ Se³ ³ ³ ³ ³
³ ³ Pumps ³rinse aspir³ rinse aspir ³ ³
³ Me³ ³ off off ³ off off ³ ³
³ Se³ ÀÄÄÄÄÄÄÄÄÄÄÄÙ ³ ³
³ Ka³ Stirrer 1 2 3 4 ³ ³
³ Ka³ off off off off ³ ³
³ Ka³ Stirring rate 3 3 3 3 ³ ³
³ Nä³ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ³ ³
³ pH³ <PG UP> lift to shift position ³ ³
³ St³ <PG DN> lift to work position; <HOME> lift to rest position ³ ³
³ ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿
³Reset ³Remote ³Stirrer³ ³Pump ³ Lift ³ Lift ³ ³Shift ³Shift ³Shift ³
³changer³lines ³on/off ³ ³on/off ³ up ³ down ³ ³left ³right ³to pos.³
ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ
The sample changer window shows the status of the connected sample
changers. The softkey bar allows the components of each sample changer
to be operated.
For each connected sample changer the data of the sample rack placed on
it are shown, i.e. sample rack type, rack code and number of beaker
positions.
The following status information is provided for each tower: lift position,
current beaker position and the result of the automatic beaker test (whether
a beaker is present or not).
The current status of each pump (rinsing or aspiration pump) and each
stirrer is shown together with the stirrer speed which can be set in 15 steps.
The stirrer speed can be entered directly in the particular entry field
selected.
The cursor keys <ç> and <è> (or <TAB>) can be used to select a
tower, pump or stirrer. A frame shows the selected changer and tower for
which a function can be triggered with a softkey. The field cursor (black
background) shows the particular stirrer selected or pump selected.
2nd changer not
connected
read-in rack
code
rack data
selection frame (marks
the selected tower)
field cursor (marks the
selected stirrer or the
selected pump
