4. Manual operationManual operation
726 Titroprocessor, Instructions for use
5757
ÚÄÄÄ Messung ÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Meas. parameters A1 ³
³ ³
³ Meas. mode pH ³
³ Ref.temp. 25 §C ³
³ ³
³ ³
³ * pH 4.598 * ³
³ ³
³ ³
³ ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
ÚÄÄÄ Messung ÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Meas. parameters Apol ³
³ ³
³ Meas. mode Upol ³
³ U(pol) 400 mV ³
³ ³
³ ³
³ * 5.34 æA * ³
³ ³
³ ³
³ ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
ÚÄÄÄ Messung ÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Meas. parameters AT ³
³ ³
³ ³
³ ³
³ ³
³ ³
³ * 21.5 §C * ³
³ ³
³ ³
³ ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
Depending on the selected measuring input the following measuring modes
can be used:
pH pH measurement, with temperature correction
U potential measurement in mV
Upol measurement of polarization current with preselected
polarization voltage
Ipol measurement of polarization voltage with preselected
polarization current
T temperature measurement with Pt100/1000
The [Start Stop] softkey starts the measurement or breaks it off again.
4.3.3 Calibration
pH sensors at measuring inputs A1, A2, Adiff, B1, B2 and Bdiff can be
calibrated. The calibration data of the particular measuring input remain
unchanged until they are altered, even if the Titroprocessor is switched off.
The [Calibr.] softkey opens the calibration window.
ÚÄÄÄ Devices & Manual Control ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Dosing devices at interface A press <TAB> for more ³
³ ³
³ Dos. drive A1 700 A2 685 A3 --- A4 --- ³
³ Reagent AgNO3 HCl ³
³ Concentr. 0.01 mol/L 0.1 mol/L ³
³ Tubing Default Default Default Default ³
ÃÄÄÄ Calibration ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³ ³
³ Meas. parameters A1: # Buffer pH val. T[§C] pH cor. Val.[mV] ³
³ ÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄ ÄÄÄÄÄ ÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄ ³
³ Signal drift 2 mV/min 1 Metrohm 4.000 23.0 3.996 175.6 ³
³ Equilibr.time 110 s 2 Metrohm 7.000 23.0 7.008 0.9 ³
³ Temperature 23.0 §C ³
³ Buffer type Metrohm 4.00 ..9.00 ³
³ ³
³ Buffer 3 pH ³
³ ³
³ ³
³ ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÄÄÙ
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿
³Preset ³ Add ³ ³ ³ Start ³ ³ ³ ³Clear ³Cancel ³ Show ³
³series ³series ³ ³ ³ Stop ³ ³ ³ ³calibr.³calibr.³ curve ³
ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ
