4.1 Overview
726 Titroprocessor, Instructions for use
5252
4 Manual operation
For manual operation or for monitoring peripheral devices (dosing devices,
sensors, sample changers, remote lines) the page ‘Devices & Manual
control’ should be called up. Press the softkey [Devices ManCtrl]
on the main page or the <MAN CONTROL>key on the keyboard.
4.1 Overview
ÚÄÄÄ Devices & Manual Control ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Dosing devices at interface A press <TAB> for more ³
³ ³
³ Dos. drive A1 700 A2 685 A3 --- A4 --- ³
³ Reagent AgNO3 HCl ³
³ Concentr. 0.01 mol/L 0.1 mol/L ³
³ Tubing Default Default Default Default ³
³ Buret type 10.0mL 20.0mL --- --- ³
³ Piston position exchange exchange ----- ----- ³
³ Dosing status ready ready ----- ----- ³
³ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ³
³ Sensors at interface A press <TAB> for more ³
³ ³
³ Meas. input A1 A2 Adiff AT ³
³ Sensor 6.0430.100 6.0232.100 ³
³ Cal. sensor 6.0232.100 ³
³ Cal.method manual Apol ³
³ Cal.date 97-12-10 14:37 ³
³ Next Calibr. 97-12-14 08:00 ³
³ pH(as) 7.000 6.987 7.000 Stirrer on ³
³ Slope 1.000 0.996 1.000 ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿ ÚÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄ¿
³Sample ³ ³Calibr.³ ³ ³ Meas ³ ³ ³ ³Stirrer³Remote ³
³changer³ ³ ³ ³ ³ ³ ³ ³ ³on/off ³lines ³
ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ ÀÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÙ
The upper part of the screen shows the status of the dosing devices which
are connected to the Titroprocessor. The lower part of the screen shows the
status of the sensors.
Each dosing device and sensor is identified by an address (A1, A2, ... ).
This stands for the corresponding connection. The type of dosing device
(685 Dosimat or 700 Dosino) is automatically recognized when the
Titroprocessor is switched on.
Address allocation scheme:
Dosing devices A1 … A4 Dosing devices at 726 Titroprocessor
B1 … B4 Dosing devices at 729 Dosimat interface
/EBus
C1 … C4 Dosing devices at 729 Dosimat interface
/EBus
Sensors A1, A2 Measuring electrodes at measuring group
‘Sensors A’
Adiff Differential amplification arrangement at
measuring group ‘Sensors A’
AT Temperature sensor Pt100/1000 of
measuring group ‘Sensors A’
Apol Polarized electrode of measuring group
‘Sensors A’
