8.4 SET
726 Titroprocessor, Instructions for use
148148
8.4 SET
Four different SET modes are available for rapid controlled titrations to a
preset endpoint; they differ only in the measured quantity or the measuring
mode:
SET_PH* measured quantity pH
SET_U* measured quantity mV
SET_UPOL* measured quantity µA (selectable pol. voltage in mV)
SET_IPOL* measured quantity mV (selectable pol. current in µA)
The following information applies to all SET modes. Any discrepances are
noted.
SET_PH* Titration to preset endpoint
Reagent Sensor
Concentr. Meas. input A1
Dos. drive A1
applies to ⇒ SET_PH*, SET_U*, SET_UPOL*, SET_IPOL*
SET modes create the same system variables as DET modes, see page
128. In addition the following variables are provided for calculating a drift
volume reduction (see page 154):
DOD Dosing duration during the titration, cumulative
ITD Time duration between conditioning and titration
Assignment parameters for SET modes:
The assignment parameters (Comment, Reagent, etc.) for the SET modes
are the same as those for the DET modes, see page 129f.
8.4.1 Specific parameters for SET modes [* Param ]
The specific parameters for the respective SET mode can be found under
the softkey [* Param ].
ÚÄÄÄ SET_PH* Parameters ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Start conditions ³
³ Volume off Pause 1 0 s ³
³ Pause 2 0 s ³
³ Extract.time 0 s ³
³ ³
³ Titration conditions ³
³ Direction auto Temperature 25.0 øC ³
³ End-point pH Time recording on ³
³ Adjustment medium Derivation off ³
³ Mpt. interval off s ³
³ ³
³ Stop conditions ³
³ Volume absolute Stop time off s ³
³ Size 99.99 mL Mpt. overflow off ³
³ Fill. rate max mL/Min ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
