User Manual

11. Introduction. Introduction
726 Titroprocessor, Instructions for use
77
1.4 The keyboard
ENTER
NEXTDELAYSKIP
LINE
FEED
MAN
CONTROL
?
><
|":
+
)
(*
&
^$
#@!
/.,MNBVCXZ
\
,
;
LKJHGFDSA
][POIUY
T
REWQ
=-0987654321
CAPS LOCK
GLP
QUIT PRINT
STOP FORM
PRINT
SCREEN
F1 F2 F3 F4 F5 F6 F7 F8 F9
START
STOP
HOLD
CONT
HELP
INS
HOME
PG UP
STATUS
DEL END PG DN
METHOD
SAMPLE
RESULT
ALTALT
ON
OFF
µ
°
The PC-like keyboard allows comfortable editing and data input in method
development and routine use.
1.4.1 Function keys (softkeys)
F1 F2 F3 F4 F5 F6 F7 F8 F9
The blue function keys are used for navigation within the window-oriented
operator dialog system. The function of these keys depends on the dialog
page and the particular window. The softkey bar at the lower edge of the
screen always shows the possible functions.
1.4.2 Hotkeys
MAN
CONTROL
STATUS
METHOD
SAMPLE
RESULT
The yellow hotkeys allow direct access to the most important functions or
dialog pages of the 726. Hotkeys can be used anywhere in dialog except
during the 'live' display of a curve while a determination is being carried out.
MAN CONTROL - opens the dialog page for manual operation
STATUS - displays the status information as shown on the main page
METHOD - opens the method selection window
SAMPLE - opens the sample input window
RESULT - opens a window which shows short result reports and statistics
