7.11 Reports
Separate reports can be defined for each mode and handled as part of the
full report of the determination. They are produced immediately after the in-
dividual mode has been concluded. They cannot just be printed out, but
can also be transferred directly to a LIMS system, e. g. the Metrohm VESUV
software.
The definition of the report of a titration or measuring mode is carried out in
the report editor window of the method; this can be opened with the softkey
[* Report] when the appropriate report has been selected with the cur-
sor.
ÚÄÄÄ * Report ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³ ³
³ Type Specification print send FF ³
³ ÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄ ÄÄÄÄ ÄÄÄÄ ³
³ Reports for V_Curve M. value yes no no ³
³ titration/ *Stand yes no no ³
³ measuring no no no ³
³ modes no no no ³
³ no no no ³
³ no no no ³
³ ³
³ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ³
³ Type Specification Print Send FF ³
³ ÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄ ÄÄÄÄ ÄÄÄÄ ³
³ Reports to be *ShrtRes yes no no ³
³ printed on no no no ³
³ full statistics no no no ³
³ counter no no no ³
³ no no no ³
³ ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ QUIT ÄÙ
The reports are printed out in the defined sequence. In the lower half of the
editing window those reports are defined which are only to be printed out
when the number of determinations which were defined for the statistical
evaluation of a series of samples has been carried out.
Type Type of report
depending on mode: C_Curve | V_Curve | T_Curve
MCurve_V | MCurve_T
*Stand | *FullRes | *ShrtRes
SamplData | CalData | *Param | MP_List
Calcn. | RawData | FormFeed | FullStat | ShrtStat
Depending on the titration or measuring mode different
reports can be selected. In curve reports the specifica-
tions of the axis, i.e. the measured quantity on the Y-axis
can be additionally defined.
C_Curve Calibration curve (only in *CAL mode)
V_Curve Volume curve (curve on the volume axis)
T_Curve Time curve (curve on the time axis)
MCurve_V Multi-curve on the volume axis
+
MCurve_T Multi-curve on the time axis
+
*Stand Standard report
*FullRes Full result report, detailed
*ShrtRes Short result report, minimal
SamplData Sample data with size
CalData Calibration data report
*Param Parameter report for mode
